Solbin® AL
Product characteristics
- Soluble in ketones, esters and chlorinated hydrocarbons. Use aromatic hydrocarbons as diluent solvents. Insoluble in alcohol, oil and aliphatic hydrocarbons
- Films made from Solbin AL are tasteless, odorless, and unaffected at room temperature by alkalis, mineral acids, alcohol, oil and aliphatic hydrocarbons.
- It combines high water resistance with low moisture permeability and low water absorption.
- List Item
- Offers superior mechanical properties such a anti-abrasion, flexibility and non-tackiness.
- Imparts good, stable dispersibility to pigments and magnetic powder in paints and in dried layers even at high packing density.
- Provides a wide choice for coating formulations due to its compatibility with various resins including polyurethane, epoxy resins, NBR, isocyanate, etc.
- Reacts with organic groups such as isocyanete to form cross linking.
Solbin AL is a thermoplastic resin consisting of polyvinyl chloride (VC) , polyvinyl alcohol (VA) and polyvinyl acetate (VAc). Due to its lower molecular weight than Solbin A, it provides lower solution viscosity.
General Properties
| Attributes | Test Results |
|---|---|
| Appearance | Light yellow powder |
| Solution Appearance | Colorless, transparent |
| Grain Size | Passes wholly through 28 mesh sieve |
| Bulk Density (g/cc) | ~0.7 |
| Composition (weight %) | |
| VC | 92.5 ± 1.5 |
| VAc | 2.5 ± 1.5 |
| VA | 5.0 ± 1.5 |
| Degree of Polymerization | 300 ± 30 |
| Molecular Weight Mn | 2.2 X 104 |
| Glass Transition Temp. (°C) | 76°C |
| Solution Viscosity (mPa*s)(MIBK/TOL. 20% @ 25°C) | 70 ± 20 |
Applications:
- Printing Ink – Solbin AL is used for coating and gravure printing ink, adding gloss to create a better decorative effect.
- Metal Container Paints – Solbin AL is used for lining food and beverage containers. Its anti-corrosiveness makes it an excellent choice for use in container lining, including applications for medicines and cosmetics. It produces a tough film that makes it ideal for coating steel and galvanized tin plates that will be fabricated later.
- Paper and Textile Coating – Solbin AL provides a water-proof protection, adding gloss for a better decorative effect.
- Magnetic Paint-Due to Solbin AL’s excellent dispersing ability for inorganic pigments such as magnetic powder, it is used as a binder and dispersing agent for magnetic paint used to produce video tapes, audio tapes, mag- netized cards and floppy disks.
How to Use:
- To ensure Solbin AL quickly goes into solution it is recommended to disperse it into a weaker solvent such as toluene and xylene then blend with the stronger solvent.
- Solbin AL is usually dissolved in a combination of both ketone (e.g. MEK and MIBK) and aromatic hydrocarbon (e.g. toluene and xylene) solvents in equal proportions, to produce a solution of 15%- 20% concentration by weight. For coatings on a porous substance, (paper or cloth), faster drying solvents such as MEK and acetone are recommended.
- For Spray coating, MIBK is used. For baking on metals, ketone with a high boiling point such cyclohexanone is used. For roll coatings, cyclohexanone or isophorone are sometimes used. Heating to around 50°C and sufficient agitation are required to speed up dissolving.
- In order to provide proper flexibility, resilience and adhesiveness to film, 5 – 20 PHR of plasticizer are added. The kind and amount of plasticizer to be added can be determined in the same manner as in the method of blend- ing polyvinyl chloride resins. Most common pigments can be employed.
- Stabilizers against heat and light are used, as with conventional polyvinyl chloride resins. The addition of about 0.2% propylene oxide, in this case, can prevent the corrosion of containers and change in paints in storage.
- Any method of coating, including spraying, roll coating and others, may be used. For roll coating, a solution of 200 – 400 seconds in Ford Cup No.4 viscosity should be used. For Spray applications a solution of 60 – 80 seconds Ford Cup No.4 viscosity should be used at an air pressure of 98 – 100psi and a liquid pressure of 20 – 30psi.
- Solbin AL does not usually provide satisfactory adhesion through air drying alone. The following chart provides the degree of adhesion to various surfaces by air drying.
- Short-time baking at 170-190°C will significantly improve adhesion and surface gloss. When primers are used, sufficient adhesion may be obtained without baking.
Solbin Printing Ink
| Grade | Composition (VC) | Composition (Vac) | Composition (Other) (Wt%) | Degree of polymerization | Average molecular Mn (×10⁴) | Glass-transition temperature (Celsius) | Solid Content (%) (mPa.s/25℃) | K-value | Features |
|---|---|---|---|---|---|---|---|---|---|
| A | Composition (VC)92 | Composition (Vac)3 | Composition (Other) (Wt%)5 Vinyl Alcohol | Degree of polymerization420 | Average molecular Mn (×10⁴)3.5 | Glass-transition temperature (Celsius)76 | Solid Content (%) (mPa.s/25℃)220 | K-value48 | Features |
| AL | Composition (VC)93 | Composition (Vac)2 | Composition (Other) (Wt%)5 Vinyl alcohol | Degree of polymerization300 | Average molecular Mn (×10⁴)2.7 | Glass-transition temperature (Celsius)76 | Solid Content (%) (mPa.s/25℃)70 | K-value42 | FeaturesLess viscous than grade A |
| C | Composition (VC)87 | Composition (Vac)13 | Composition (Other) (Wt%) | Degree of polymerization420 | Average molecular Mn (×10⁴)3.6 | Glass-transition temperature (Celsius)70 | Solid Content (%) (mPa.s/25℃)150 | K-value48 | FeaturesGas-tight and highly resistant to waterHighly resistant to chemicals. Highly transparent |
| C5R | Composition (VC)79 | Composition (Vac)21 | Composition (Other) (Wt%) | Degree of polymerization350 | Average molecular Mn (×10⁴)2.6 | Glass-transition temperature (Celsius)68 | Solid Content (%) (mPa.s/25℃)60 | K-value45 | Features |
| CH | Composition (VC)86 | Composition (Vac)14 | Composition (Other) (Wt%) | Degree of polymerization650 | Average molecular Mn (×10⁴)5 | Glass-transition temperature (Celsius)73 | Solid Content (%) (mPa.s/25℃)700 | K-value57 | FeaturesMore viscous than Grade C Highly transparent and resistant to heat and weather |
| CL | Composition (VC)86 | Composition (Vac)14 | Composition (Other) (Wt%) | Degree of polymerization300 | Average molecular Mn (×10⁴)2.5 | Glass-transition temperature (Celsius)70 | Solid Content (%) (mPa.s/25℃)60 | K-value42 | FeaturesLess viscous than grade C Highly soluble Highly transparent |
| CN | Composition (VC)89 | Composition (Vac)11 | Composition (Other) (Wt%) | Degree of polymerization750 | Average molecular Mn (×10⁴)4.2 | Glass-transition temperature (Celsius)75 | Solid Content (%) (mPa.s/25℃)40*1 | K-value60 | FeaturesHigh viscosity, forms strong coating film Highly transparent |
| CNL | Composition (VC)90 | Composition (Vac)10 | Composition (Other) (Wt%) | Degree of polymerization200 | Average molecular Mn (×10⁴)1.2 | Glass-transition temperature (Celsius)76 | Solid Content (%) (mPa.s/25℃)30 | K-value33 | FeaturesLess viscous than grade CN, highly soluble Highly transparent |
| M5 | Composition (VC)85 | Composition (Vac)14 | Composition (Other) (Wt%)1 Dicarboxylic acid | Degree of polymerization430 | Average molecular Mn (×10⁴)3.3 | Glass-transition temperature (Celsius)69 | Solid Content (%) (mPa.s/25℃)130 | K-value49 | FeaturesStrongly adheres to metals, aluminum, and cellophane |
| TA3 | Composition (VC)83 | Composition (Vac)4 | Composition (Other) (Wt%)13 Hydroxyalkyl ac rylate | Degree of polymerization350 | Average molecular Mn (×10⁴)3.2 | Glass-transition temperature (Celsius)65 | Solid Content (%) (mPa.s/25℃)80 | K-value45 | FeaturesFavorably disperses pigments and magnetic powdersMore thermostable than Grade A, less viscous |
Note: The values in the table are representative values, not standard values.
Solbin Coating Paint
| Grade | Composition (VC) | Composition (Vac) | Composition (Other) (Wt%) | Degree of polymerization | Average molecular Mn (×10⁴) | Glass-transition temperature (℃) | Solid Content (%) (mPa.s/25℃) | K-value | Features |
|---|---|---|---|---|---|---|---|---|---|
| A | Composition (VC)92 | Composition (Vac)3 | Composition (Other) (Wt%)5 Vinyl Alcohol | Degree of polymerization420 | Average molecular Mn (×10⁴)3.5 | Glass-transition temperature (℃)76 | Solid Content (%) (mPa.s/25℃)220 | K-value48 | Features |
| AL | Composition (VC)93 | Composition (Vac)2 | Composition (Other) (Wt%)5 Vinyl Alcohol | Degree of polymerization300 | Average molecular Mn (×10⁴)2.7 | Glass-transition temperature (℃)76 | Solid Content (%) (mPa.s/25℃)70 | K-value42 | FeaturesLess viscous than grade A |
| C | Composition (VC)87 | Composition (Vac)13 | Composition (Other) (Wt%) | Degree of polymerization420 | Average molecular Mn (×10⁴)3.6 | Glass-transition temperature (℃)70 | Solid Content (%) (mPa.s/25℃)150 | K-value48 | FeaturesGas-tight and highly resistant to water. Highly resistant to chemicals. Highly transparent. |
| C5R | Composition (VC)79 | Composition (Vac)21 | Composition (Other) (Wt%) | Degree of polymerization350 | Average molecular Mn (×10⁴)2.6 | Glass-transition temperature (℃)68 | Solid Content (%) (mPa.s/25℃)60 | K-value45 | Features |
| CH | Composition (VC)86 | Composition (Vac)14 | Composition (Other) (Wt%) | Degree of polymerization650 | Average molecular Mn (×10⁴)5 | Glass-transition temperature (℃)73 | Solid Content (%) (mPa.s/25℃)700 | K-value57 | FeaturesMore viscous than Grade C. Highly transparent and resistant to heat and weather. |
| CL | Composition (VC)86 | Composition (Vac)14 | Composition (Other) (Wt%) | Degree of polymerization300 | Average molecular Mn (×10⁴)2.5 | Glass-transition temperature (℃)70 | Solid Content (%) (mPa.s/25℃)60 | K-value42 | FeaturesLess viscous than grade C. Highly soluble. Highly transparent. |
| CN | Composition (VC)89 | Composition (Vac)11 | Composition (Other) (Wt%) | Degree of polymerization750 | Average molecular Mn (×10⁴)4.2 | Glass-transition temperature (℃)75 | Solid Content (%) (mPa.s/25℃)40*1 | K-value60 | FeaturesHigh viscosity, forms strong coating file. Highly transparent. |
| M5 | Composition (VC)85 | Composition (Vac)14 | Composition (Other) (Wt%)1 Dicarboxylic acid | Degree of polymerization430 | Average molecular Mn (×10⁴)3.3 | Glass-transition temperature (℃)69 | Solid Content (%) (mPa.s/25℃)130 | K-value49 | FeaturesStrongly adheres to metals, aluminum, and cellophane |
| TA3 | Composition (VC)83 | Composition (Vac)4 | Composition (Other) (Wt%)13 Hydroxyalkyl acrylate | Degree of polymerization350 | Average molecular Mn (×10⁴)3.2 | Glass-transition temperature (℃)65 | Solid Content (%) (mPa.s/25℃)80 | K-value45 | FeaturesFavorably disperses pigments and magnetic powders. More thermostable than Grade A, less viscous |
Note: The values in the table are representative values, not standard values.
General Properties
| Attributes | Test Results |
|---|---|
| Appearance | Light yellow powder |
| Solution Appearance | Colorless, transparent |
| Grain Size | Passes wholly through 28 mesh sieve |
| Bulk Density (g/cc) | ~0.7 |
| Composition (weight %) | |
| VC | 92.5 ± 1.5 |
| VAc | 2.5 ± 1.5 |
| VA | 5.0 ± 1.5 |
| Degree of Polymerization | 300 ± 30 |
| Molecular Weight Mn | 2.2 X 104 |
| Glass Transition Temp. (°C) | 76°C |
| Solution Viscosity (mPa*s)(MIBK/TOL. 20% @ 25°C) | 70 ± 20 |
Note: The values in the table are representative values, not standard values.
